FANUC Series 30i/31i Specifications of Auxiliary Function Table with Delay Time Additional Manual Page 9

Additional Manual
A-79969E
4. Signals
Path Table Delay time Signal
PTDLY<Fn531#0>
(2
[Classification] Output signal
[Function] The signal indicates that the Path Table Operation is outputting M codes with
delay time.
[Output condition] The signal turns "1" by the following condition.
- Path Table Operation output M codes with delay time.
The signal turns "0" by the following condition.
- Reset status.
- When "the table time when the M code becomes effective" passes.
Note
When PTDLY signal is "1", Path Table Override signals PTOV1 to
PTOV7<G0520#0 to #6> are ignored. Override keeps the value at
outputting M codes.
(2
Sheet
Title
Draw
No.
02 Oct. 22.'05 Addition or Modification of (2.
Ed. Date Design Description
Date Jan.31.’05 Desig. T.Watanabe Apprv. Y.Takeuchi
FANUC Series 30i/31i
Specifications of
Auxiliary function table with delay time
FANUC LTD
9/12
