OPERATION

8. DATA INPUT/OUTPUT

B–63174EN/02

358

Parameters and pitch error compensation data are entered using different

screens. This chapter describes operations required.

Parameters are loaded into the memory of the controller unit from a floppy

or NC tape. The input format is the same as the output format. See

V–

8.6.2. When a parameter is loaded which has the same data number as

a parameter already registered in the memory, the loaded parameter

replaces the existing parameter.

Inputting parameters

1 Make sure the input device is ready for reading.

When using the Power Mate i–D2, select a path for which parameters

are to be entered, with the path selection switch or MDI keyboard.

2 When using a floppy, search for the required file according to the

procedure in V–

8.2.

3 Press the EMERGENCY STOP button on the machine operator’s panel.

4 Press function key

OFFSET

SETTING

5 Press the soft key [SETING]

for chapter selection.

6 Enter 1 in response to the prompt for writing parameters (PWE).

Alarm P/S100 (indicating that parameters can be written) appears.

7 Press soft key

SYSTEM

8 Press chapter selection soft key [PARAM], Then the parameter

screen appears.

9 Press soft key [(OPRT)].

10 Press the rightmost soft key

(next–menu key).

11 Press soft keys [READ] and [EXEC].

Parameters are read into memory. Upon completion of input, the

“INPUT” indicator at the lower–right corner of the screen disappears.

12 Press function key

OFFSET

SETTING

13 Press soft key [SETING] for chapter selection.

14 Enter 0 in response to the prompt for writing the setting data

parameters.

15 Turn the power to the CNC back on.

16 Release the EMERGENCY STOP button on the machine operator’s

panel.

8.6

INPUTTING AND

OUTPUTTING

PARAMETERS AND

PITCH ERROR

COMPENSATION

DATA

8.6.1

Inputting Parameters

Procedure (CRT/MDI)
