OPERATION

B–63174EN/02

11. SETTING AND DISPLAYING DATA

449

The current position of the tool in the relative coordinate system can be

reset to 0 or preset to a specified value as follows:

Procedure to Set the Axis Coordinate to a Specified Value

1 Enter an axis address (such as X or Y) on the screen for the relative

coordinates. The indication for the specified axis blinks and the soft

keys change as shown on the left.

2 S To reset the coordinate to 0, press soft key

[ORGIN]. The relative

coordinate for the blinking axis is reset to 0.

S To preset the coordinate to a specified value, enter the value and

press soft key [PRESET]. The relative coordinate for the blinking

axis is set to the entered value.

Procedure to Reset All Axes

1 Press soft key [(OPRT)].

2 Press soft key [ORIGIN].

3 Press soft key [ALLEXE].

The relative coordinates for all axes are reset to 0.

Bit 4 (DRL) of parameter No. 3104 can be used to select whether the

displayed values include tool length offset.

Bit 3 (PPD) of parameter No. 3104 is used to specify whether the

displayed positions in the relative coordinate system are preset to the

same values as in the workpiece coordinate system when a coordinate

system is set by a G92 command or when the manual reference position

return is made.

Only the coordinates for the first to fifth axes are displayed initially

whenever when there are six or more controlled axes. Pressing the

[ABS]

soft key displays the coordinates for the sixth and subsequent axes.

Explanations

D Setting the relative

coordinates

Procedure for CRT/MDI

ORIGIN

2 4 6. 9 1 2

Y 9 1 3. 7 8 0

AUTO

PRESET

Procedure for CRT/MDI

ORIGIN

EXEC

RELABS ALL

(OPRT)

ALLEXE

D Display including

compensation values

D Presetting by setting a

coordinate system

D Displaying the sixth and

subsequent axes

(Power Mate i–H)
