Connecting and Maintenance Manual for Fanuc Panel I Additional Manual Page 2

Additional Manual
EDI
T
SHEET
DRAW. NO.
CUS
T
T
ITLE
DESCRIPTION
DESIG.DATE
Connecting and Maintenance Manual
for FANUC PANEL i
A-81000E
1 / 79
Introduction
This manual describes mounting information of the FANUC PANEL i or CNC display unit with
Peasonal Computer function (Old name: Intelligent Terminal with PCI Bus) with the following
FANUC CNC to the machine tools.
In case of using the FANUC PANEL i with FANUC CNC, refer to manuals for the following FANUC
CNC with this manual.
Application
Product Name Abbreviation
FANUC Series 150i - MODEL A 150i-MA
FANUC Series 150i - MODEL B 150i-MB
150i
FANUC Series 160i - MODEL TA 160i-TA
FANUC Series 160i - MODEL MA 160i-MA
FANUC Series 160i - MODEL PA 160i-PA
FANUC Series 160i - MODEL LA 160i-LA
160i
FANUC Series 160i - MODEL TB 160i-TB
FANUC Series 160i - MODEL MB 160i-MB
160i-B
FANUC Series 180i - MODEL TA 180i-TA
FANUC Series 180i - MODEL MA 180i-MA
FANUC Series 180i - MODEL PA 180i-PA
180i
FANUC Series 180i - MODEL TB 180i-TB
FANUC Series 180i - MODEL MB 180i-MB
180i-B
FANUC Series 210i - MODEL TA 210i-TA
FANUC Series 210i - MODEL MA 210i-MA
210i
FANUC Series 210i - MODEL TB 210i-TB
FANUC Series 210i - MODEL MB 210i-MB
210i-B
FANUC Series 150 - MODEL TB
150-TB
FANUC Series 150 - MODEL MB
150-MB
150-B
FANUC Series 160 - MODEL TC
160-TC
FANUC Series 160 - MODEL MC
160-MC
160-C
FANUC Series 180 - MODEL TC
180-TC
FANUC Series 180 - MODEL MC
180-MC
180-C
FANUC Series 210 - MODEL MB
210-MB
FANUC Series 210 - MODEL TB
210-TB
210-B
FANUC Power Mate i- MODEL D Power Mate i-D
FANUC Power Mate i- MODEL H Power Mate i-H
Power Mate i
FANUC Series 0i – MODEL TA 0i – TA
FANUC Series 0i – MODEL MA 0i - MA
0i
Refer to the following manual which describes the FANUC High Speed Serial Bus and the
interface board for CNC.
Name Spec.
FANUC High Speed Serial Bus Type 2
Connecting and Maintenance Manual
A-73527E
All page changed.04 01.04.01
Sugitani
05
02.03.07
Sugitani
1-(Marked 5 added, page No.
modified),4,15,26,55,59,62-74,79/79
5
5
