1. Outline Table
1.1 Outline Table Basic Unit
Name Specification Remark Outline
A08B-0082-B001,
A13B-0193-B001
10.4” color LCD, without Touch Panel, without Softkey
A08B-0082-B002,
A13B-0193-B002
10.4” color LCD, without Touch Panel, with Softkey
A08B-0082-B003,
A13B-0193-B003
10.4” color LCD, with Touch Panel, without Softkey
A08B-0082-B004,
A13B-0193-B004
10.4” color LCD, with Touch Panel, with Softkey
2.1
A08B-0082-B011,
A13B-0193-B011
12.1” color LCD, without Touch Panel, without Softkey
A08B-0082-B012,
A13B-0193-B012
12.1” color LCD, without Touch Panel, with Softkey
A08B-0082-B013,
A13B-0193-B013
12.1” color LCD, with Touch Panel, without Softkey
A08B-0082-B014,
A13B-0193-B014
12.1” color LCD, with Touch Panel, with Softkey
2.2
A08B-0082-B021
15.0” color LCD, without Touch Panel, without Softkey
A08B-0082-B023
15.0” color LCD, with Touch Panel, without Softkey
2.3
A08B-0082-B031
10.4” color LCD, without Touch Panel, without Softkey
A08B-0082-B032
10.4” color LCD, without Touch Panel, with Softkey
A08B-0082-B033
10.4” color LCD, with Touch Panel, without Softkey
A08B-0082-B034
10.4” color LCD, with Touch Panel, with Softkey
A08B-0082-B035
10.4” color LCD, without Touch Panel, without Softkey
A08B-0082-B036
10.4” color LCD, without Touch Panel, with Softkey
A08B-0082-B037
10.4” color LCD, with Touch Panel, without Softkey
A08B-0082-B038
10.4” color LCD, with Touch Panel, with Softkey
2.1
A08B-0082-B041
12.1” color LCD, without Touch Panel, without Softkey
A08B-0082-B042
12.1” color LCD, without Touch Panel, with Softkey
A08B-0082-B043
12.1” color LCD, with Touch Panel, without Softkey
A08B-0082-B044
12.1” color LCD, with Touch Panel, with Softkey
A08B-0082-B045
12.1” color LCD, without Touch Panel, without Softkey
A08B-0082-B046
12.1” color LCD, without Touch Panel, with Softkey
A08B-0082-B047
12.1” color LCD, with Touch Panel, without Softkey
A08B-0082-B048
12.1” color LCD, with Touch Panel, with Softkey
2.2
A08B-0082-B051
15.0” color LCD, without Touch Panel, without Softkey
A08B-0082-B053
15.0” color LCD, with Touch Panel, without Softkey
A08B-0082-B055
15.0” color LCD, without Touch Panel, without Softkey
PANEL i
Basic Unit
A08B-0082-B057
15.0” color LCD, with Touch Panel, without Softkey
2.3
04 01.04.01 Sugitani All pages changed.
