Connecting and Maintenance Manual for Fanuc Panel I Additional Manual Page 61

Additional Manual
Connecting and Maintenance Manual
for FANUC Intelligent Terminal
EDIT
DRAW. NO.
CUST
TITLE
DESCRIPTION
DESIG.
DATE
A-81000E
58
/
SHEET
No Cause Measure
5 Boot up from CD-ROM. When CD-ROM drive is connected to PANEL i and bootable CD-
ROM is inserted to the drive, PANEL i starts up from CD-ROM.
Please remove CD-ROM at starting up. (There is no item about
boot device in BIOS settings).
11 Power is not good. - Is the fuse blown out? Exchange the fuse.
Check the cause.
. Is +24V input correct? Input correctly.
- If all user cables are disconnected, Check user cables.
has the state been changed?
. Is it good if remove PCI board? Check PCI board.
-Is main board of PANEL i good?
Yes
No
Yes
No
04 01.04.01 Sugitani All pages changed.
Yes
No
Yes
No
