B–63682EN/01

14. TOOL COMPENSATION FUNCTION

NC FUNCTION

101

Tool position compensation along the X– and Y–axes can be effected for

tools specified by a code consisting of character T and one to four digits

that follow it. The amount of compensation is specified in the least

command increment defined on the tool registration menu during

installation. (Up to 136 tools, values: Positive number consisting of eight

digits)

CAUTION

If an inch/metric switch–over option is specified, and the

measurement unit used in the machine is different from that

used in the input system, a maximum possible error is the

sum of half the least input increment and half the least

command increment. This error will not be accumulated.

This function can be used for die–indexable tools. It simplifies

mechanical adjustment like reference position adjustment performed

during tool mounting by effecting automatic C–axis compensation for

tool indexing. The amount of compensation and the tool number for the

die–indexable tool are specified by parameters. (Up to 20 tools with tool

numbers of 1 to 9999)

14.1

TOOL OFFSET

COMPENSATION

14.2

C–AXIS POSITION

COMPENSATION
