18. CUSTOM MACRO

NC FUNCTION

123

- WHILE (<conditional expression>) DO m (m = 1, 2, 3)

END m

While <conditional expression> is satisfied, blocks from DO m to

END m is repeated.

When <conditional expression> is no more satisfied, it is executed

from the block next to

END m block.

Example

#120 = 1 ;

WHILE [#120 LE 10] DO 1 ;

#120=#120+1 ;

END

Repeated 10 times.

The format is the same as the sub program.

0 Macro number ;

Custom macro body

M99 ;

- Simple call

G65 P (macro number) L (times to repeat)

<argument assignment> ;

A value is set to a variable by <argument assignment>.

Write the actual value after the address.

Example A5.0E3.2M13.4

There is a regulation on which address (A – Z) corresponds to which

variable number.

- Modal call

G66 P (macro number) L (times to repeat)

<argument assignment> ;

Each time a move command is executed, the specified custom macro

body is called. This can be canceled by G67.

This function is useful when drilling cycles are programmed as custom

macro bodies.

D Format of custom macro

body

D Custom macro

instruction
