North American Operator Panels for Machine Tools
using i Series CNCs or Power Mate i
Table 1-1. Covered Products
Lamp Version LED version
Part Number Description Part Number Description
44A739025-G01 Operator Panel Series i 520mm
Lamp Standard
44A739025-G11 Operator Panel Series i 520
LEDS Standard
44A739025-G02 Operator Panel Series i 400mm
Lamp Standard
44A739025-G12 Operator Panel Series i 400
LEDS Standard
44A739025-G03 Operator Panel Series i 520mm
Lamp Chrysler
44A739025-G13 Operator Panel Series i 520
LEDs Chrysler
44A739025-G04 Operator Panel Series i 400
Lamp Chrysler
44A739025-G14 Operator Panel Series i 400
LEDS Chrysler
44A739026-G01 Operator Panel/Custom Series i Lamp 44A739026-G11 Operator Panel/Custom Series i LEDS
44A739026-G02 Operator Panel/Custom Series i Lamp 44A739026-G12 Operator Panel/Custom Series i LEDS
44A739026-G03 Operator Panel Series i 520
Lamp MPG+8PB
44A739026-G13 Operator Panel Series i 520
LEDS MPG+8PB
44A739026-G04 Operator Panel, Strippit 180i NA NA
44A739026-G05 Operator Panel, Fellows FS-400 NA NA
44A739026-G06 Operator Panel, Fellows 10-4, Series I NA NA
44A739026-G07 Operator panel/Lamps, i Series, Strippit 44A739026-G17 Operator panel/LEDs, i Series, Strippit
44A739026-G08 Operator Panel Series i 520
Lamp 8PB Custom
44A739026-G18 Operator Panel Series i 520
LEDS 8PB Custom
44A739026-G09 Operator Panel Series i 520
Lamp MFO&SSO
44A739026-G19 Operator Panel Series i 520
LEDS MFO&SSO
44A739026-G10 Operator Panel Series i 520
Lamp MPG+8PB Chrysler
44A739026-G20 Operator Panel Series i 520
LEDS MPG+8PB Chrysler
The GE Fanuc North American Operator Panel has been adapted for use with the i Series Computer
Numerical Controls (CNCs). As a result, its size is now more compact, and its wiring is simplified.
