Several variations of the North American Operator Panel are identified in Table 1-3. These variations
include a width of 520 mm or 400 mm, with or without MPG, and various configurations of rotary switches
and pushbuttons. If your specific application requires additional modification, please contact your local GE
Fanuc sales or application engineer.
Table 1-3. Variations of the Operator Panel
Category MPG
Pushbutton &
Switch
Variations
400 mm
Width
520 mm
Width
Comments
Separate Standard
North American
Operator Panel
44A739025-G02
(Lamps)
44A739025-G12
(LEDs)
44A739025-G01
(Lamps)
44A739025-G11
(LEDs)
E-STOP, 3 rotary switches
(all with inhibit contacts),
Memory Protect Key
Switch, 45 pushbuttons,
including Power ON/OFF.
Separate ON/OFF removed; 6
extra pushbuttons; 2
extra key switches.
N/A 44A739026-G01
(Lamps)
44A739026-G11
(LEDs)
Variations are all with
respect to 44A739025-G01.
Separate 1 rotary switch
removed.
N/A 44A739026-G02
(Lamps)
44A739026-G12
(LEDs)
Variations are all with
respect to 44A739025-G01.
Connection Unit
A02B-2002-0470
Source Type (CE)
72DI / 56DO
Includes 3 MPG
interfaces.
Must be ordered
separately.
Built-in 8 extra pushbuttons
located above MPG.
N/A 44A739026-G03
(Lamps)
44A739026-G13
(LEDs)
Variations are all with
respect to 44A739025-G01.
Included Cables
Note: I/O Link
Cable must be
ordered separately.
Includes
50 cm cable
for Built-in
MPG.
Connects Operator
Panel to the
Connection Unit,
when mounted on
brackets provided
at rear of panel.
Connects Operator
Panel to the
Connection Unit,
when mounted on
brackets provided
at rear of panel.
All internal cables are
supplied with Operator
Panel.
CE Mark Labels One set is included with
accessories shipped with
Operator Panel.
Optional Cable Set 44C739032-G01 44C739032-G01 Optional 1 meter cable set
available for remote mount.
Recommended
Power Cable Set
44C742962-G01 44C742962-G01 Connects 24VDC to the
CNC, Connection Unit and
Operator Panel. Maximum
cable length 1 meter.
Extra Contacts for
E-STOP
44A724659-006
(Normally Open)
44A724659-007
(Normally Closed)
44A724659-006
(Normally Open)
44A724659-007
(Normally Closed)
For panels assembled after
March 1999.
LED Upgrade Kit 44A736871-G02
(53 pushbuttons)
44A736871-G01
(45 pushbuttons)
44A736871-G01
(45 pushbuttons)
Standard panel has 45
pushbuttons.
Pushbutton
Replacement
Toolkit
44A739089-G01 44A739089-G01 One included with
accessories shipped with
Operator Panel.
Previous page
Next page

Contents Summary of Operator Panels for i Series Controls Operators manual
