Operator Panels for i Series Controls Operators manual Page 21

Operators manual
1-9
The connectors listed in Table 1-5 are identified for reference use only. GE Fanuc recommends that
connectors required for installation be specified and ordered with the CNC control hardware, as listed in the
GE Fanuc ordering instructions. Separate connectors may be required for custom configurations or as
renewal parts.
Note
In some cases, assembled cables can be provided in shorter lead times
than separate connector components.
Table 1-5. Power Connectors and Connector Kits
Part Number Quantity per Description
GE Fanuc North American Operator Panel
44A731497-002 1 Connector PL1 (+24VDC Switched).
44A717191-450 1 Connector PL2 (Rotary Switches and Additional I/O).
44A717191-901 50 Crimp Pins for PL2 Connector.
N/A - Replace Cable 2 Connector PL3 and PL4 (Control ON / Control OFF).
A02B-0120-K342 2 Connector PL53 and PL54 (50 Conductor Ribbon style).
A02B-0120-K342 2 Connector CE53 and CE54 (50 Conductor Ribbon style).
A02B-0120-K301 2 Kit for JD1A / JD1B , I/O Link (20 Pin Honda PCR solder type).
A02B-0120-K303 1 Kit JA3 MPG (15 Pin Honda PCR solder type).
A02B-0120-K324 2 Kit for CDP1 , +24VDC Power (Amp Type X 1-178288-3).
Series 16i/18i/21i LCD (Integrated) Units
A02B-0120-K324 1 Kit for CP1A , +24VDC Power (Amp Type X 1-178288-3).
A02B-0120-K323 1 Kit for CP1B , +24VDC Power (Amp Type Y 2-178288-3).
A02B-0120-K301 1 Kit for JD1A , I/O Link (20 Pin Honda PCR solder type).
Series 16i/18i/21i Stand-Alone Units
A02B-0120-K324 1 Kit for CP1A , +24VDC Power (Amp Type X 1-178288-3).
A02B-0120-K323 1 Kit for CP1B , +24VDC Power (Amp Type Y 2-178288-3).
A02B-0120-K301 1 Kit for JD1A , I/O Link (20 Pin Honda PCR solder type).
A02B-0120-K324 1 Kit for LCD CP1A , +24VDC Power (Amp Type X 1-178288-3).
A02B-0120-K323 1 Kit for LCD CP1B , +24VDC Power (Amp Type Y 2-178288-3).
(continued)
Previous page
Next page
