Table 1-6. Power Connectors and Connector Kits (continued)
Part Number Quantity per Description
Power Mate i – Models D and H
A02B-0120-K324 1 Kit for LCD CP1 , +24VDC Power (Amp Type X 1-178288-3).
A02B-0120-K323 1 Kit for LCD CP2 , +24VDC Power (Amp Type Y 2-178288-3).
A02B-0120-K301 1 Kit for CP41 , Display (20 pin Honda PCR solder type).
A02B-0120-K324 1 Kit for CPD1 , CRT/MDI +24VDC Power (Amp Type X 1-178288-3).
A02B-0120-K324 1 Kit for CPD2 , CRT/MDI +24VDC Power (Amp Type X 1-178288-3).
A02B-0120-K301 1 Kit for JD13 , CRT/MDI (20 pin Honda PCR solder type).
A02B-0120-K301 1/2 Kit for JD1A / JD1B , I/O Link (20 Pin Honda PCR solder type).
Series 15i CNC
A02B-0120-K321 1 Kit for CP1 , 200VAC Input (Amp 1-178128-3).
A02B-0120-K321 2 Kit for CP2 & CP3 , 200VAC Outputs (Amp 1-178128-3).
A02B-0120-K322 1 Kit for CP4 , Control On / Control Off (Amp 1-178129-6).
A02B-0120-K323 1 Kit for CP5 , +24VDC Power (Amp Type Y 2-178288-3).
A02B-0120-K324 1 Kit for CP6 , +24EVDC Power (Amp Type X 1-178288-3).
A02B-0120-K324 1 Kit for LCD CP1A , +24VDC Power (Amp Type X 1-178288-3).
A02B-0120-K323 1 Kit for LCD CP1B , +24VDC Power (Amp Type Y 2-178288-3).
A02B-0120-K301 1/2 Kit for JD1A / JD1B , I/O Link (20 Pin Honda PCR solder type).
