Operator Panels for i Series Controls Operators manual Page 36

Operators manual
1-24
Table 1-8. Renewal Parts (continued)
Part Number Quantity per Description
44A736871-G01 1 LED Conversion Kit (45-pushbutton panel).
44A736871-G02 1 LED Conversion Kit (53-pushbutton panel).
44A739089-G01 1 Lamp Extractor Kit.
44A724659-003 1 E-STOP Pushbutton.
44A724659-006 1 Extra Normally Open Contact for E-STOP.
44A724659-007 3 Extra Normally Closed Contact for E-STOP.
44C742962-G01 1
Operator Panel Power Cable Set for the Series 16i/18i/21i CNCs and Power
Mate i Motion Controller.
44A739097-G01 1
Operator Panel Power Cable Set for the Series 15i CNC.
44A739032-G01 1 Operator Panel Connection Unit Extended Length Ribbon Cable Set.
Suitable for mounting the Connection Unit up to one meter from the
Operator Panel.
44A717186-051 Varies LED Red 24V 6CHIP T1 3/4
44A717186-052 Varies LED Green 24V 6CHIP T1 3/4
44A717186-053 Varies LED Yellow 24V 6CHIP T1 3/4
In addition, the North American Operator Panels with MPG (44A739026-G03 & 44A739026-G13) add the unique
items listed in Table 1-9 below.
Table 1-9. Renewal Parts Unique to North American Operator Panels with MPG 44A739026-
G03 or 44A739026-G13
Part Number Quantity per Description
A860-0202-T001 1 Manual Pulse Generator (MPG) Device.
44C741873-007 1 MPG Cable (0.5m).
44C742962-008 1 Pushbutton Cable Harness for PL2.
