Series 16i /18i /21i Additional Manual Page 11
Additional Manual
4. Signal
Program check signal
PGCK<G0290#5>
[Classification] Input signal
[Function] Specify the program check mode.
[Operation] When this signal is “1”, the program check mode is effective.
When this signal is “0”, the program check mode is not effective.
Note
Alarm PS5365 occurs when the program check signal PGCK <G0290#5>
is changed while a program is executing.
Program check mode signal
PRGMD<F0290#5>
[Classification] Output signal
[Function] Notify that the program check mode is active.
[Operation] This signal turns to “1” under both of the following conditions.
• The program check signal PGCK <G0290#5> is “1”.
• MEM or DNC mode is selected.
3)
In case that the parameter PGR (No.3454#3) is set to “1”, the
data are saved under both of the above conditions. This signal
turns to “1” when the save of data is completed.
This signal turns to “0” under one of the following conditions.
• The program check signal PGCK <G0290#5> is “0”.
• Except MEM or DNC mode is selected.
3)
In case that the parameter PGR (No.3454#3) is set to “1”, the
data are restored under one of the above conditions. This
signal turns to “0” when the restore of data is completed.
Signal address
#7 #6 #5 #4 #3 #2 #1 #0
G0290 PGCK
#7 #6 #5 #4 #3 #2 #1 #0
F0290 PRGMD
Edit
Apprv.
Desig.
Sheet
TITLE
Draw
No.
Date
Design
Descri
p
tion
Date
FANUC Series 16i/18i/21i–MB, 18i–MB5
Program check function Specifications
A-79461E
02
2004.3.29
Addition of 2)
2004.2.29
11
/
15
03
2004.6.25
Addition of 3)
04
2004.6.30
Addition of 4)
05
2004.7.26
Addition of 5)
