Series 16i /18i /21i Additional Manual Page 2

Additional Manual
1. General
The program format check and the stroke limit check are done without axes
movements by the program execution during the program check mode.
The program check is executed with the maximum feedrate of CNC system and
without the acceleration / deceleration regardless of the specified data.
And after the program check is completed, the reference position return is not
necessary because the workpiece coordinate system preset is executed automatically
at the program check mode end.
3)
In case that the parameter PGR (No.3454#3) is set to “1”, the data, which are
changed during the program check mode, are restored to the data at the program
check mode start when ending the program check mode.
By this, after ending the program check mode, the automatic operation can be
executed with the data before the program check mode start.
Edit
Apprv.
Desig.
Sheet
TITLE
Draw
No.
Date
Design
Descri
p
tion
Date
FANUC Series 16i/18i/21i–MB, 18i–MB5
Program check function Specifications
A-79461E
02
2004.3.29
Addition of 2)
2004.2.29
2
/
15
03
2004.6.25
Addition of 3)
04
2004.6.30
Addition of 4)
05
2004.7.26
Addition of 5)
Previous page
Next page
