Series 16i /18i /21i Additional Manual Page 5
Additional Manual
• Machine Coordinate Display For Program Check
During the program check mode, it is possible to change the display of machine
coordinates from the actual machine coordinates to the machine coordinates for the
program check by setting the parameter PGM (No.13114#7).
And it is possible to change the display of machine coordinate for each axis from the
actual machine coordinate to the machine coordinate for the program check by setting
the parameter PGA (No.3115#4).
The diagnosis No.301 (machine position) always shows the actual machine
coordinate (the machine position from the reference position) regardless of the
parameter PGM and PGA setting.
2)
• Display during Program Check Mode
During the program check mode, “PRG-CHK” blinks on the CNC display.
3)
• Tool life
If tool life management command or tool management command is specified during
the program check mode, tool life is not counted.
• Auxiliary function
When the parameter PGS (No.3001#6) is set to “0”, during the program check mode,
the auxiliary function is not executed same as that the auxiliary function lock signal
AFL <G005#6> is “1”. That is, M, S, T, and B function code signals and strobe signals
are not output.
When the parameter PGS (No.3001#6) is set to “1”, during the program check mode,
the M, S, T, and B function code signals and strobe signals are output same as the
normal operation.
During the dynamic graphic display or Manual Guide i simulation mode, when it is
necessary to output the M, S, T, and B function code signals and strobe signals,
please set the following parameters.
Parameter PGS (No.3001#6) = 1
Parameter PGR (No.3454#3) = 1
Parameter MST (No.6503#1) = 1
4)
5)
Edit
Apprv.
Desig.
Sheet
TITLE
Draw
No.
Date
Design
Descri
p
tion
Date
FANUC Series 16i/18i/21i–MB, 18i–MB5
Program check function Specifications
A-79461E
02
2004.3.29
Addition of 2)
2004.2.29
5
/
15
03
2004.6.25
Addition of 3)
04
2004.6.30
Addition of 4)
05
2004.7.26
Addition of 5)
