Series 16i /18i /21i Additional Manual Page 9
Additional Manual
3)
• Control axis select signal (PMC axis control)
In case that the parameter PGR (No.3454#3) is set to “1”, alarm PS5364 occurs when
the control axis select signal (PMC axis control) EAX* <G0136> is changed from “0”
to “1” or from “1” to “0” during the program check mode.
5)
• Restore of data
When the power off request alarm is generated during the program check mode and
the CNC power is turned off immediately, the changed data still remain. Therefore, if a
restore of data is necessary, turn off the CNC power after ending the program check
mode and restoring the saved data.
• Programmable parameter entry (G10)
The parameter PGR (No.3454#3) and the parameter PGS (No.3001#6) can not be
changed by programmable parameter entry (G10). When G10 L50 is commanded to
these parameter bits, alarm PS5364 occurs.
• Cycle start
In case that the parameter PGR (No.3454#3) is set to “1”, the cycle start signal
<G007#2> are invalid during the data saving and restoring.
4)
• Dynamic graphic display
In case that the parameter PGR (No.3454#3) is set to “1” and during the program
check mode, the dynamic graphic display can not be executed. If the path graphic or
solid graphic of the dynamic graphic display is started, alarm PS5364 occurs.
And if the program check signal PGCK <G0290#5> is changed from “0” to “1” during
the dynamic graphic display execution, alarm PS5365 occurs.
• Unusable functions
The program check function can not be used in combination with the following
functions.
・ Angular axis control
・ Arbitrary angular axis control
・ Customer’s board
If the angular axis control / arbitrary angular axis control option or customer’s board
option is set, alarm PS5364 occurs at the program check mode start.
• Unavailable command
Following functions can not be specified during the program check mode. If the
following functions are specified, alarm PS5364 occurs.
・ High speed cycle cutting
・ High precision contour control
・ AI high precision contour control /AI NANO high precision contour control
・ Tool center point control
