Series 16i /18i /21i Additional Manual Page 12
Additional Manual
5. Parameters
#7 #6 #5 #4 #3 #2 #1 #0
13114 PGM
[Data type] Bit
PGM The machine coordinate display during the program check mode
0 : The actual machine coordinate (the machine position from the reference position)
is displayed.
1 : The machine coordinate for the program check is displayed.
2)
#7 #6 #5 #4 #3 #2 #1 #0
3115 PGA
[Data type] Bit axis
PGA The machine coordinate display during the program check mode for each axis
0 : The display is according to the parameter PGM (No.13114#7) setting.
1 : The machine coordinate for the program check is displayed.
Note
1. The machine coordinate of the axis, whose the control axis select
signal (PMC axis control) EAX* <G0136> is “1”, shows the actual
machine coordinate regardless of the parameter PGM and PGA
setting.
2. The diagnosis No.301 (machine position) always shows the actual
machine coordinate regardless of the parameter PGM and PGA
setting.
#7 #6 #5 #4 #3 #2 #1 #0
1490 PGF
[Data type] Bit
PGF The program check execution feedrate at circle, involute, spiral and conical
interpolation is
0 : Dry run rate.
1 : Maximum feedrate of CNC system.
Note
If this parameter is set to “1”, the feedrate clamp, override, and dry run
become invalid for circle, involute, spiral and conical interpolation.
Therefore, the stroke limit check may not be done properly when there is
a move command close to the stroke limit.
Edit
Apprv.
Desig.
Sheet
TITLE
Draw
No.
Date
Design
Descri
p
tion
Date
FANUC Series 16i/18i/21i–MB, 18i–MB5
Program check function Specifications
A-79461E
02
2004.3.29
Addition of 2)
2004.2.29
12
/
15
03
2004.6.25
Addition of 3)
04
2004.6.30
Addition of 4)
05
2004.7.26
Addition of 5)
