B–63604EN/01

8. DATA INPUT/OUTPUTOPERATION

539

Loading memory data

1 Press the rightmost soft key (continuous menu key) on the ALL

IO screen, described in Section III–8.10.1.

2 Press soft key [M–CARD].

3 Place the CNC in the emergency stop state.

4 When a memory card is inserted, the state of the memory card is

displayed as shown below.

S 0 T0000

EDIT **** - - EMG- - 12: 15: 00

[FORMAT] [ SAVE ] [ LOAD ] [DELETE] [ ]

READ/PUNCH(M–CARD) O1234 N12345

CNC RAM

512K byte 2. 000M byte S- RAM

File ( 1/ 1)

SRAM0_5A. FDB 524288 byte 97/ 01/ 23

Select : All data

Memory card

Message

5 Press soft key [LOAD].

6 With cursor keys

and , select the file to be loaded from the

memory card.

A system having 1.0MB or 2.5MB of CNC RAM may require the

loading of multiple files. All or selective data load can be specified

for each file.

7 To perform selective data loading, press soft key [SELECT], then

select the data to be loaded. Each time the soft key is pressed, the

information displayed changes cyclically, as shown below.

All data Program Parameter Offset PMC data

Macro dataC

8 After checking the file selection, press soft key [EXEC].

9 During loading, the message “RUNNING” blinks, and the number of

bytes loaded is displayed in the message field.

10 Upon the completion of loading, the message “COMPLETED” is

displayed in the message field, with the message “PRESS RESET

KEY.” displayed on the second line.

11 Press the RESET key. The messages are cleared from the screen.

Procedure

EXECCAN

SELECT
