Order Specification for Servo HRV3 Function Additional Manual Page 14
Additional Manual
Edit. DATE Design
Description
DRAW. NO.
A-65428E
CUST.
01 00/08/22
New issue
SATOU
FANUC Series 15i
Order specification for Servo
HRV3
SHEET
13 /
17
TITLE
5-1-4
Axis control card for Additional axis board (for 17-24 axis
•
Note 1
Specification High speed
HRV current
control
Type Refer to
4-1-5
B10 A02B-0261-J315 Not available
Type A+A (2 FSSB
lines)
CASE 3,4
Additional axis board
servo control card for
servo HRV3
for 9 or 10
axes (17 or 18)
C10 A02B-0261-J325 Max 10axes
Type B+A (3 FSSB
lines)
CASE 2
B12 A02B-0261-J316 Not available
Type A+A (2 FSSB
lines)
CASE 3,4
C12 A02B-0261-J336 Max 12axes
Type B+A (3 FSSB
lines)
CASE 2
Additional axis board
servo control card for
servo HRV3
for 11 or 12
axes (19 or 20)
D12 A02B-0261-J326 Max 10axes
Type B+B (4 FSSB
lines)
CASE 1
Note2
B14 A02B-0261-J317 Not available
Type A+A (2 FSSB
lines)
CASE 3,4
C14 A02B-0261-J327 Max 14axes
Type B+B (4 FSSB lines) CASE 1
Additional axis board
servo control card for
servo HRV3
for 13 or 14
axes (21 or 22)
D14 A02B-0261-J337 Max 8axes
Type B+A (3 FSSB
lines)
CASE 2
B16 A02B-0261-J318 Not available
Type A+A (2 FSSB
lines)
CASE3,4
C16 A02B-0261-J328 Max 16axes
Type B+B (4 FSSB lines) CASE 1
Additional axis board
servo control card for
servo HRV3
for 15 or 16
axes (23 or 24)
D16 A02B-0261-J338 Max 8axes
Type B+A (3 FSSB lines) CASE2
Note 2. Please specify axis control card for 8 axis for the Main CPU board.
In case of high speed HRV is used
Please specify the type B axis control card for the Main CPU, and type A or B card for the Additional axis board
according to the necessity.
In case of high speed HRV is not used
Please specify the type A card both for the Main CPU and for the Additional axis board.
Please set high speed HRV current control from 1st
FSSB line on the Main CPU board sequentially.
Note 3. On the additional board one FSSB line (5th line) is used for the high speed HRV current control, and
another
line (6th line)of FSSB is used for a present amplifier.
5-1-5 Combination of 4-1-5 main CPU board and axis control card on addition axis board
(17-24 axes)
.CASE1
In case of Hi
g
h s
p
eed HRV current control ada
p
ted to more than 21 axes.
•
COP10A-2
COP10A-1
Main CPU
Additional Axis
COP10A-2
COP10A-1
Type B axis control
card
Type B axis control
card
6 FSSB line
5 FSSB line
1st FSSB line
2nd FSSB line
High speed HRV current control can be used in six
FSSB lines. (Total 24 axes)
Please set High speed HRV current control from 1st
FSSB line sequentially.
Please refer to item 3.
COP10A-2
COP10A-1
Type B axis control
card
3rd FSSB line
4th FSSB line
4axes
4 axes
1-4 axes
4 axes
4axes
4 axes
