Order Specification for Servo HRV3 Function Additional Manual Page 17

Additional Manual
Edit. DATE Design
Description
DRAW. NO.
A-65428E
CUST.
01 00/08/22
New issue
SATOU
FANUC Series 15i
Order specification for Servo
HRV3
SHEET
16 /
17
TITLE
5-4. Servo amplifier for Servo HRV3
Name Specification for high Speed
HRV current control
for Servo HRV3
Alpha servo
Single axis
SVM1-12 A06B-6096-H101#H NG OK
Under 20Ap SVM1-20 A06B-6096-H102#H NG OK
SVM1-40S A06B-6096-H103#H OK OK
Alpha servo SVM1-40L A06B-6096-H104#H OK OK
Single axis SVM1-80 A06B-6096-H105#H OK OK
40Ap – 130Ap SVM1-130S A06B-6096-H116#H OK OK
SVM1-130 A06B-6096-H106#H OK OK
SVM2-12/12 A06B-6096-H201#H NG OK
Alpha servo SVM2-12/20 A06B-6096-H202#H NG OK
Double axes SVM2-20/20 A06B-6096-H203#H NG OK
Under 20Ap SVM2-12/40 A06B-6096-H204#H NG OK
SVM2-20/40 A06B-6096-H205#H NG OK
Alpha servo SVM2-40/40 A06B-6096-H206#H OK OK
Double axes SVM2-40/80 A06B-6096-H207#H OK OK
40Ap – 130Ap SVM2-80/80 A06B-6096-H208#H OK OK
SVM2-40L/40L A06B-6096-H209#H OK OK
Alpha servo
Single axis
Over 240Ap
NG NG
Alpha servo
Triple axes
NG NG
Beta servo NG NG
Note
For high speed HRV current control: All functions of Servo HRV3 can be used.
For Servo HRV3: Only high speed HRV current control function of Servo HRV3 function can
not be used. But this amplifier can be connected with the amplifier, which is
set high speed HRV current control, in the same FSSB line together.
5-5. Separate Detector I/F unit for Servo HRV3
Specification Remark
Separate Detector I/F unit
Basic 4 axis
A02B-0236-C205
