FANUC Series 30i-MODEL A
Rotary table dynamic fixture offset
1.5 Example
Parameter
Parameter 7580=4 (C–axis)
Parameter 7581=1 (X–axis)
Parameter 7582=2 (Y–axis)
Parameter 7583～7588=0
7575#0(X)=1 (The offset is valid for the X–axis.)
7575#0(Y)=1 (The offset is valid for the Y–axis.)
7570#0=0 (When bit 0 of parameter 7570 is set to 1, the values in
square brackets ([ ]) are calculated.)
Data of fixture offset 1 (n = 1)
C= 180.0 (reference angle)
X= -10.0
Y= 0.0
When these parameters and data are set, the machine operates as shown
below :
Table 1.5 Example of fixture offset
Position on the
workpiece coordinate
system (ABSOLUTE)
Position on the
machine coordinate
system (MACHINE)
Fixture offset
Coordinates
Program
X Y C X Y C X Y C
N1 G90 G00 X0 Y0 C90. ; 0.0 0.0 90.0 0.0 0.0 90.0 0.0 0.0 0.0
N2 G54.2 P1 ; 0.0
[0.0
0.0
-10.0
90.0
90.0]
0.0
[0.0
10.0
0.0
90.0
90.0]
0.0
[0.0
10.0
10.0
0.0
0.0]
N3 G01 X10. Y2. F100. ; 10.0 2.0 90.0 10.0 12.0 90.0 0.0 10.0 0.0
N4 G02 X2. Y10. R10. ; 2.0 10.0 90.0 2.0 20.0 90.0 0.0 10.0 0.0
N5 G01 X0 Y0 ; 0.0 0.0 90.0 0.0 10.0 90.0 0.0 10.0 0.0
…
The values enclosed in brackets ([ ]) apply when bit 0 (FTP) of parameter
No. 7570 is set to 1.
