Appendix 7. Notes on using SD.EXE
In the servo software for Learning control, The using way of SD.EXE is different from in standard servo
software. We describe the difference and cautions. Regarding the details of SD.EXE, refer to the manual
attached SD.EXE.
7.1 Dip-switch and data contents
You can select the data content by Dip-switch (4 bits) on Digital check-board.
Dip-switch (B3, B2, B1, B0) Standard series Learning series
0, 0, 0, 0 Vcmd (L-axis) Error (L-axis) Error (L-axis)
0, 0, 0, 1 Tcmd (L-axis) Tcmd (L-axis) Tcmd (L-axis)
0, 0, 1, 0 Vcmd (M-axis) Mcmd (L-axis) Error (M-axis)
0, 0, 1, 1 Tcmd (M-axis) Tcmd (M-axis)
0, 1, 0, 0 TSA (L-axis) TSA (L-axis) TSA (L-axis)
0, 1, 0, 1 TSA (M-axis) TSA (M-axis)
0, 1, 1, 0 Pos. (L-axis) Pos. (L-axis)
0, 1, 1, 1 Pos. (M-axis) Pos. (M-axis)
1, 0, 0, 0 Pos. (L-axis) *1 Pos. (L-axis) *1
1, 0, 0, 1 Pos. (M-axis) *1
1) Regarding the display unit, you should select “POS” in SYSTEM setting screen of SD.EXE, and set the
following.
Error Display unit (mm) : 1pulse=Least detective unit (mm) / 32
Mcmd Display unit (mm/sec) : 1pulse=Least detective unit (mm) / 32 / Velocity loop period (sec)
2) If you set non-zero value for No.2115, TSA is not output.
3) When you set 4788 for No.2115, the marked “*1” is output.
7-2. Limit of measurement
The speed which it is possible to measure is below 1024 Least detective unit per Velocity loop period.
(Example) When Velocity loop 1ms and 0.1µm Least detective unit, the speed limit is 6m/min.
You can expand the speed limit.
No.2115 Limit of measurement *2 Display unit *3
4787 2048 2 times of Least detective unit
4786 4096 4 times of Least detective unit
4785 8192 8 times of Least detective unit
4784 16384 16 times of Least detective unit
*2 Least detective unit per Velocity loop period
*3 “POS” in SYSTEM setting screen of SD.EXE
In case that the speed gets over the above limit, there is a possibility of interpolation by “CTRL-j” in
SD.EXE after gathering the data.
