CZi Sensor (with Serial Interface) Additional Manual Page 13

Additional Manual
Draw.
Title
Na
g
atomo 04.02.16 01
PAGE
13／14
FANUC LTD.
A-72587-0148EN
Descri
p
tionDesi
g
n Date Edit
.
CZi Sensor (with Serial Interface)
(10)Setting of parameters
The number of feedback pulse per 1 revolution differs along with the teeth number of CZi Sensor(with Serial
Interface). Set parameters shown below.
(10).1 Series and editions of applicable servo software
90B0/YA
90B1/01 and subsequent editions.
(10).2 In case of using CZi Sensor (with Serial Interface) for Synchronous Bilt-in Motor DiS Series
It is neccesary to apply “pole position detection function” in order to adjust AMR offset.
（CZi Sensor 1024S）
Set parameters as Pulsecoder whose resolution is 1000000 per revolution.
Setting example
44 polar Synchronous Built-in Motor, gear ratio 1 : 1 , detection unit 1/1000[deg].
F・FG=360000／1000000= 36/100
Velocity pulses=8192
Position pulses=12500
AMR=00101100 （44）
Reference counter=360000 (or the divided number)
（CZi SENSOR512S）
Set parameters as Pulsecoder whose resolution of 500000 per revolution.
Setting example
88 polar Synchronous Built-in Motor, gear ratio 1 : 1 , detection unit 1/1000[deg].
F・FG=360000／500000= 36/50
Velocity pulses=4096
Position pulses=6250
AMR=01011000 （88）
Reference counter=360000（or the divided number）
F・FG (Necessary position FB pulses per motor revolution) / 1000000
Velocity pulses 8192
Position pulses 12500
A
MR Set half of pole numbers in binary number
Reference counter Number of position FB pulses per motor revolution,
or an inte
g
e
r
number that divides into it.
F・FG (Necessary position FB pulses per motor revolution) / 500000
Velocity pulses 4096
Position pulses 6250
A
MR Set pole numbers in binary number
Reference counter Number of position FB pulses per motor revolution,
or an integer number that divides into it.
