CZi Sensor (with Serial Interface) Additional Manual Page 14

Additional Manual
Draw.
Title
Na
g
atomo 04.02.16 01
PAGE
14／14
FANUC LTD.
A-72587-0148EN
Descri
p
tionDesi
g
n Date Edit
.
CZi Sensor (with Serial Interface)
(10).3 In case of using CZi Sensor (with Serial Interface) as Separate Detector
（CZi SENSOR1024S）
Set parameters as rotary type encoder with FANUC Serial Interface
Setting example
gear ratio 1 : 1, detection unit 1/1000[deg].
Ｆ・ＦＧ=360000/1000000 = 36/100
Position pulses = 12500
Reference counter = 360000 (or the divided number)
（CZi SENSOR512S）
Set parameters as rotary type encoder whose pulse is 500000/rev.
Setting example
gear ratio 1 : 1, detection unit 1/1000[deg].
Ｆ・ＦＧ=360000/500000 = 36/50
Position pulses =6250
Reference counter = 360000(or the divided number)
F・FG (Necessary position FB pulses per detector revolution) / 1000000
Position pulses 12500×（reduction ratio from motor to table）
Reference counter Number of position FB pulses per detector revolution
or
an integral
number
that divides into it
F・FG (Necessary position FB pulses per detector revolution) / 500000
Position pulses 6250×（reduction ratio from motor to table）
Reference counter Number of position FB pulses per detector revolution
or
an integral
number
that divides into it
