FANUC Series 16
i
/18
i
/21
i
– TA/TB
Direct input of offset value measured B
for 2 spindle lathe
Jan.31.02
9/13
Tool offset number select signals
OFN0
∼
∼∼
∼
OFN5<G039#0
∼
∼∼
∼
#5>
OFN6
∼
∼∼
∼
OFN9<G040#0
∼
∼∼
∼
#3>
[Classification]
[Classification][Classification]
[Classification] Input signal
[Function]
[Function][Function]
[Function] Selects the tool offset number.
[Operation]
[Operation][Operation]
[Operation] When the mode for writing tool compensation is selected, the cursor is
automatically positioned on the tool geometry compensation number selected by
these signals.
A tool offset number is specified by 10–bit binary number. Number 0 to 998
corresponds to the compensation number 1 to 999.
Work origin offset write
mode select signal
WOQSM<G039#6>
[Classification]
[Classification][Classification]
[Classification] Input signal
[Function]
[Function][Function]
[Function] Select the mode for writing the work origin offset.
[Operation]
[Operation][Operation]
[Operation] When this signal is turned “1” in a manual operation mode, the mode for writing
the work origin offset is selected. The control unit then automatically switches
the screen displayed on the CRT to the tool geometry compensation screen and
blinks the “WSFT” status display in the bottom of the screen to notify that the
mode has been changed to the mode for writing the work origin offset.
Work origin
offset write signal
WOSET<G040#7>
[Classification]
[Classification][Classification]
[Classification] Input signal
[Function]
[Function][Function]
[Function] Automatically calculates and sets the work origin offset amount for the
workpiece coordinate system.
[Operation]
[Operation][Operation]
[Operation] When this signal turns to “1” in the mode for the work origin offset for the
workpiece coordinate system, it triggers automatic calculation and setting of the
Z-axis work origin offset amount for the workpiece coordinate system.
Measured spindle
select signal
S2TLS <G040#5>
[Classification]
[Classification][Classification]
[Classification] Input signal
[Function]
[Function][Function]
[Function] The spindle measuring the tool offset amount and Z-axis work origin offset
amount is selected.
[Operation]
[Operation][Operation]
[Operation] When this signal turns to “1” in the mode for the work origin offset for the
workpiece coordinate system, it triggers automatic calculation and setting of the
Z-axis work origin offset amount for the workpiece coordinate system.
Note
This signal is available only when the parameter No.5005#5 (QNI) =1.
