FANUC Series 16
i
/18
i
/21
i
– TA/TB
Direct input of offset value measured B
for 2 spindle lathe
Jan.31.02
8/13
5. Signal
Tool offset write mode select
Signal GOQSM<G039#7>
[Classification]
[Classification][Classification]
[Classification] Input signal
[Function]
[Function][Function]
[Function] The mode for writing tool compensation is selected.
[Operation]
[Operation][Operation]
[Operation] When this signal is turned “1” in a manual operation mode, the mode for writing
tool compensation is selected. The control unit then automatically switches the
screen displayed on the CRT to the tool geometry compensation screen and
blinks the “OFST” status display in the bottom of the screen to notify that the
mode has been changed to the mode for writing tool compensation.
Tool offset write signal
+
++
+
MIT1
#1
,
−
−−
−
MIT1
#1
,
+
++
+
MIT2
#1
,
−
−−
−
MIT2
#1
<X004#2, #3, #4, #5> (Path1)
+
++
+
MIT1
#2
,
−
−−
−
MIT1
#2
,
+
++
+
MIT2
#2
,
−
−−
−
MIT2
#2
<X013#2, #3, #4, #5> (Path2)
+
++
+
MIT1
#3
,
−
−−
−
MIT1
#3
,
+
++
+
MIT2
#3
,
−
−−
−
MIT2
#3
<X011#2, #3, #4, #5> (Path3)
[Classification]
[Classification][Classification]
[Classification] Input signal
[Function]
[Function][Function]
[Function] Each of these signals inhibits the tool from being fed along the corresponding
axis during manual operation. When signal GOQSM for selecting the mode for
writing tool compensation is set to “1”, the manual feed is inhibited and also the
tool geometry compensation along the axis is automatically calculated and the
result is set in tool compensation memory.
[Operation]
[Operation][Operation]
[Operation] When these signals are turned “1”, the control unit operates as follows:
•
Inhibits tools from being fed along the corresponding axis during manual
operation.
+MIT1: Inhibits the tool from being manually fed in the positive direction
along the X-axis.
–MIT1 : Inhibits the tool from being manually fed in the negative
direction along the X-axis.
+MIT2 : Inhibits the tool from being manually fed in the positive direction
along the Z-axis.
–MIT2 : Inhibits the tool from being manually fed in the negative
direction along the Z-axis.
•
When signal GOQSM for selecting the mode for writing tool compensation is
turned “1”, the manual feed interlock signal also automatically calculates the
tool geometry compensation for the tool compensation number pointed to by
the cursor and sets the result in tool compensation memory.
Note
This signal is used as the manual feed interlock signal in each axis direction.
