6. Parameter
#7 #6 #5 #4 #3 #2 #1 #0
5005 QNI
[
[[
[Data type
Data typeData type
Data type]
]]
]Bit
QNI
QNIQNI
QNI In Direct input of offset value measured B or this function
0 Not automatically select the tool offset number
1:Automatically selects a tool offset number
#7 #6 #5 #4 #3 #2 #1 #0
5051 WNI DSN
[
[[
[Data type
Data typeData type
Data type]
]]
]Bit
DSN
DSNDSN
DSN When this function is used:
0 : One touch sensor is used for both main spindle 1 and main spindle 2.
1 : Two touch sensors are used for both main spindle 1 and main spindle 2.
WHI
WHIWHI
WHI When a workpiece reference point offset value is set in workpiece coordinate
system memory with the tool setter function for 1–turret, 2–spindle lathes:
0 : The value is set at the current cursor position.
1 : A memory is automatically selected. (The workpiece coordinate system
memory set in parameter No.5054 or No.5055 is selected.)
5020 Tool offset number used for the input of tool offset value measured B
[
[[
[Data type
Data typeData type
Data type]
]]
]Byte
[Valid data range]
[Valid data range][Valid data range]
[Valid data range] 1 to the number of tools to be compensated.
Set the tool offset number used for the input of tool offset value measured B
function or this function (i.e. when workpiece coordinate system shift value is
set).
This parameter is valid when the tool offset number is not selected automatically
(Parameter No.5005#5(QNI)=0).
5015
Distance (X1P) between reference position and X axis + contact surface
on the touch sensor 1
5016
Distance (X1M) between reference position and X axis - contact surface
on the touch sensor 1
5017
Distance (Z1P) between reference position and Z axis + contact surface
on the touch sensor 1
5018
Distance (Z1M) between reference position and Z axis - contact surface
on the touch sensor 1
