FANUC Series 16
i
/18
i
/21
i
– TA/TB
Direct input of offset value measured B
for 2 spindle lathe
Jan.31.02
10/13
Measured spindle check signal 1
S1MES <F062#3>
Measured spindle check signal 2
S2MES <F062#4>
[Classification]
[Classification][Classification]
[Classification] Output signal
[Function]
[Function][Function]
[Function] The spindle under measurement is specified.
[Output condition]
[Output condition][Output condition]
[Output condition] These signals check which head is being measured in the tool offset write mode
or the workpiece origin offset write mode according to the S2TLS (spindle
measurement select) signal.
If spindle 1 is selected, S1MES = 1 and S2MES = 0. If spindle 2 is selected,
S1MES = 0 and S2MES = 1.
Signal address
#7 #6 #5 #4 #3 #2 #1 #0
X004 -MIT2
#1
+MIT2
#1
-MIT1
#1
+MIT1
#1
X011 -MIT2
#3
+MIT2
#3
-MIT1
#3
+MIT1
#3
X013 -MIT2
#2
+MIT2
#2
-MIT1
#2
+MIT1
#2
#7 #6 #5 #4 #3 #2 #1 #0
G039 GOQSM WOSQM OFN5 OFN4 OFN3 OFN2 OFN1 OFN0
G040 WOSET S2TLS OFN9 OFN8 OFN7 OFN6
#7 #6 #5 #4 #3 #2 #1 #0
F062 S2MES S1MES
