FANUC Series 16
i
/18
i
/21
i
– TA/TB
Direct input of offset value measured B
for 2 spindle lathe
Jan.31.02
13/13
5053 Bias for tool offset numbers for measured tool offset value setting
[Data type]
[Data type][Data type]
[Data type] Byte
[Unit of data]
[Unit of data][Unit of data]
[Unit of data] Number
[Valid data range]
[Valid data range][Valid data range]
[Valid data range] 1 to maximum tool offset count
When this function is used, this parameter allocates tool offset numbers for
measured tool offset measurement values to spindle 1 and spindle 2.
Example:
Example:Example:
Example: When the tool offset count is 16 pairs
Tool offset number
When setting = 8 When setting = 10
For spindle 1
1
∼
81
∼
10
For spindle 2
9
∼
16 11
∼
16
5054 G code of workpiece coordinate system selected for spindle 1
5055 G code of workpiece coordinate system selected for spindle 2
[Data type]
[Data type][Data type]
[Data type] Byte
[Unit of data]
[Unit of data][Unit of data]
[Unit of data] Number
[Valid data range]
[Valid data range][Valid data range]
[Valid data range] 54 to 59
When the parameter No.5051 (WNI) is set to 1, in each of these parameters, a
workpiece coordinate system from G54 to G59 for workpiece reference point
offset value setting.
NOTE
If 0 is set for this parameter, or if the maximum tool offset count is exceeded,
the following is assumed:
Tool offset number
16 32 64 99
For spindle 1
1
∼
81
∼
16 1
∼
32 1
∼
49
For spindle 2
9
∼
16 17
∼
32 33
∼
64 50
∼
99
Tool offset number
400 999
For spindle 1
1
∼
200 1
∼
449
For spindle 2
201
∼
400 450
∼
999
NOTE
If the value set in this parameter is 0, or if the value falls outside the valid data
range, 54 is assumed for the workpiece coordinate system memory for spindle
1, while 57 is assumed for the workpiece coordinate system memory for
spindle 2.
