FANUC Series 16
i
/18
i
/21
i
– TA/TB
Direct input of offset value measured B
for 2 spindle lathe
Jan.31.02
4/13
The tool offset number can be selected by the parameter No. 5005#5 (QNI)
manually or automatically.
•
QNI=0 (Manual selection)
Set the cursor to the desired tool compensation number by operating the MDI
(such as page and cursor keys).
•
QNI=1 (Automatic selection)
In the offset write mode, the cursor is set to the desired tool compensation
number, using the tool compensation number input signal.
For spindle 1, the cursor is set to a tool compensation number selected by the
input signal.
For spindle 2, the cursor is set to the sum of the value specified in parameter
No. 5053 and the tool compensation number selected by the input signal. In
this case, the MDI cannot be used to change the cursor position on the offset
screen.
Note
If the tool compensation number specified by the tool compensation number
input signal is out of range, the last tool compensation amount memory
number for each spindle is set up.
