3. Improvements in Level-up Type
In the level-up type C2000-E, the following items have been modified from the conventional
type as improvement. (Detail specification may be changed due to further improvements)
3.1. Addition of Processing Mode Change Function
Processing mode of level-up type C2000-E can be selected from either “High-Power Mode” or
“Fine Mode” by changing laser gas pressure in oscillator, depending on the processing
material or the processing objectives.
Caution: Parameters are set to High-Power Mode at shipment.
Abstract of Processing Mode Change Function
High-Power Mode (High Power Cutting Mode)
Continuous output of maximum 2.5kW is enabled, enhancing the cutting performance
of non-ferrous materials. Electric power consumption is maintained as low as the
conventional type.
Fine Mode (Fine Cutting Mode)
Cut surface quality of thin to medium thickness sheets are improved. Rated output is
unchanged 2kW. However, operation at even higher efficiency is realized.
3.2. Modifications of Maximum Output
Conventional Type: 2000W
Level-up Type: High-Power Mode (High-Power Cutting Mode): 2500W
Fine Mode (Fine Cutting Mode) : 2000W
Ranges of command for each mode are as follows:
Output
Command
Pc(W)
Pulse Frequency
Command
Fr(%)
Pulse Duty
Command
Du(%)
0-2500 5-2000 0-100 High-power Mode
2501-2700 5-2000 0-50
Fine Mode 0-2000 5-2000 0-100
3.3. Modifications of Cavity Mirror Specifications
Cavity mirrors of a new specification are adopted and they are incompatible with the
conventional type.
Mirror Specifications of level-up type C2000-E
Output Coupler A04B-0813-D200 1pcs/UNIT
Rear Mirror A04B-0813-D201 1pcs/UNIT
Folding Mirror A04B-0817-D202 3pcs/UNIT
