2.2. Comparison table of level up type and conventional type
Item Conventional Level up type Remark
Specification
A04B-0813-B301
-B311
A04B-0813-B321
-B322
Rated Power 2000W
←
Maximum Power 2000W 2500W
Maximum Pulse Peak
Power
2700W
←
Freq less than500Hz
Duty less than 50%
Pulse Enhancement Available
2001W – 2700W
Available
2501W – 2700W
Pulse feedback Available Available
Only by FS16i-LB
Beam Mode Low Order Mode
←
Beam Diameter (Short)
<∅27mm ←
At exit
Beam Diameter (Long)
<∅24mm ←
At exit
Polarizer
45°linear ←
Divergence (Full Angle)
<2 mrad ←
Pulse Frequency 5 - 2000Hz
←
Pulse Duty 0 - 100%
←
Laser gas
Composition
CO
2
:He:N
2
=
5:40:55
CO
2
:He:N
2
=
5:60:35
Gas Consumption Approx.10 l/h
←
Water Flow Rate
>75 l/min ←
Recommended
Cooling capacity
>22.1kW ←
Required input power 33kVA
←
Weight ca. 700kg
←
Warning light Available
← （option）
Guide Laser Available
←
Standard
Anti Reflection Mirrors Available None
（option）
CNC
FS16i-LA, 16i-LB Only FS16i-LB
CE Marking Available
←
Available
Dimensions 2050(W) x750(D)
x1056(H)
←
Refer to diagram
Gas and water ports Existing
←
Refer to diagram
