0i/0i Mate - Model C Connection manual (Hardware) Page 6

Connection manual (Hardware)
B–64113EN/01
PREFACE
p–2
This manual consists of Chapters 1 to 13 and Appendixes.
Chapter title Description
Chapter 1
CONFIGURATION
Outlines connections for the Series 0i/0i Mate and guides the reader
concerning additional details.
Chapter 2
TOTAL CONNECTION DIAGRAM
This chapter shows the total connection diagram.
Chapter 3
INSTALLATION
This chapter describes the installation conditions for the Series 0i/0i Mate.
1) Required power supply
2) Heat generated
3) Connector arrangement on the control unit
4) Noise prevention
Chapter 4
CONNECTING THE POWER SUPPLY
This chapter describes how to connect the power supply.
Chapter 5
CONNECTING PERIPHERAL UNITS
This chapter describes how to connect the following peripheral devices:
1) MDI units
2) I/O devices (via RS232C)
3) Manual pulse generators
Chapter 6
CONNECTING THE SPINDLE UNIT
This chapter describes how to connect the spindle servo unit, the spindle
motor.
Chapter 7
SERVO INTERFACE
This chapter describes how to connect the servo unit and the servo unit.
Chapter 8
CONNECTION TO FANUC I/O Link
This chapter describes the use of FANUC I/O Link to expand the machine
interface I/O.
Chapter 9
CONNECTION OF I/O Link SLAVE
DEVICES
This chapter describes the addresses and connector pins for signals
transferred between the Series 0i/0i Mate and the machine.
Describes the I/O unit for Series 0i.
Chapter 10
EMERGENCY STOP SIGNAL
This chapter describes the handling of emergency stop signals. The user
must read this chapter before attempting to operate the CNC.
Chapter 11
HIGH–SPEED SERIAL BUS (HSSB)
This chapter describes the high–speed serial bus (HSSB) supported by the
Series 0i.
Chapter 12
FANUC DNC2
This chapter describes connections for the FANUC DNC2.
Chapter 13
OTHER NETWORK CONNECTION
This chapter lists manuals related to the Ethernet, DeviceNet, and other
networks
Appendix A External dimensions of unit
B20–pin interface connectors and cables
C Connection cable (Supplied from US)
D Optical fiber cable
E Liquid crystal display (LCD)
F Memory card interface
G Procedure for fixing the memory card
Configuration of the
manual
