B–64113EN/01

4. POWER SUPPLY CONNECTION

CAUTION

The battery must be replaced with the power of the machine

turned on (the servo amplifier turned on).

Note that, if batteries are replaced while no power is

supplied to the CNC, the recorded absolute position is lost.

The battery for the absolute pulse coder built into the motor is installed

in the servo amplifier. For how to connect and replace the battery, refer

to the following manuals:

D FANUC SERVO MOTOR αis series Maintenance Manual

D FANUC SERVO MOTOR βi series Maintenance Manual

D FANUC SERVO MOTOR βi series (I/O Link Option) Maintenance

Manual

4.4.3

Battery for Absolute

Pulse Coder Built into

the Motor (6VDC)
