Basic SPINDLE Tuning using SERVO GUIDE
5.4. Tuning velocity loop gain
It is necessary to tune velocity loop gain to enhance the accuracy.
Please tune velocity loop gain according to chapter 2.
(1) Parameters
Parameter
No
16i/18i/21i, 0i
Standard setting value Description
4046 30 Velocity loop proportional gain (HIGH) CTH1=0
4047 30 Velocity loop proportional gain (LOW) CTH1=1
4054 50 Velocity loop integral gain (HIGH) CTH1=0
4055 50 Velocity loop integral gain (LOW) CTH1=1
(2) Other parameters related to velocity loop tuning.
Parameter
No
16i/18i/21i, 0i
Standard setting value Description
4094 0
The constant of disturbance compensating *1)
(Acceleration feedback gain)
4097 0 Spindle speed feedback gain *2)
4162 0
Velocity loop integral gain for cutting
feed (HIGH) *3)
CTH1=0
4163 0
Velocity loop integral gain for cutting
feed (Low) *3)
CTH1=1
*1) By setting this parameter, stability in cutting can be improved.
Set a value from 500 to 2000.
*2) When a belt is used to connect the spindle with the motor, control stability may be improved by
feeding back the spindle speed.
Set the about the same value as specified in parameter No.4046 (velocity loop proportional gain.)
*3) When 0 is set in these parameters, the values set is No.4054 and No.4055 are valid.
A-53866E-456/05 (31/34)
