Basic Spindle Tuning Using Servo Guide Additional Manual Page 34

Additional Manual
Basic SPINDLE Tuning using SERVO GUIDE
5.7. Spindle Fine Acceleration/Deceleration (FAD) function
Fine Acceleration/Deceleration (FAD) function with feed-forward is very effective to enhance accuracy
and to reduce cycle time.
When you use FAD function for servo axis, you can use spindle FAD function on Cs contouring mode.
(1) Parameters
Please set the parameters according to the following table
Parameter No
16i/18i/21i, 0i
Description Setting
4394#3 Spindle FAD function 1
4394#4 Acc./Dec. type during spindle FAD Same setting for the servo axis (2209#2)
4344 Feed-forward coefficient Same setting for the servo axis (2092)
4037 Velocity loop feed-forward coefficient 0
4408 FAD time constant Same setting for the servo axis (2109)
4409 Feed-forward timing adjustment coefficient -500 (recommended setting)
A-53866E-456/05 (34/34)
