FANUC Series 16i/160i-LB,LPB Pulse Power Feedback Function Additional Manual Page 10

Additional Manual
EDIT
DATE DESIGN
DESCRIPTION
TITLE
Pulse Power Feedback Function
A-81053-080
Page
９/16
01 04.09.14 M.Andou New registration
FANUC LTD
DR
A
W
No.
02 05.11.08 M.Andou Change of approx. power monitor
（A gray area where stability is confirmed is recommended. ）
Value in table：Feedback target value of pulse instruction (Unit:W)
Table 4-1. Pc=500W table for pulse feedback (Unit:W)
10Hz 50Hz 150Hz 250Hz 500Hz 700Hz 1kHz 2kHz
10%
12 2 0 0 0 0 0 0
25%
44 12 4 3 0 0 0 0
35%
71 31 6 5 2 0 0 0
50%
108 74 11 8 8 3 2 2
70%
164 132 44 29 57
87 88 59
90%
232 192
192 216 206 196 197 185
Table 4-2. Pc=1000W table for pulse feedback (Unit:W)
10Hz 50Hz 150Hz 250Hz 500Hz 700Hz 1kHz 2kHz
10%
67 52 27 4 0 0 0 0
25%
201 198 152 126 40 7 11 3
35%
286 303 237 212 123 95 140
59
50%
420 448 384 348 329
341 368 283
70%
609 629 574 556
571 584 605 543
90%
819 801 795 804 802 793 800 775
Table 4-3. Pc=1500W table for pulse feedback (Unit:W)
10Hz 50Hz 150Hz 250Hz 500Hz 700Hz 1kHz 2kHz
10%
125 114 137 88 4 0 0 0
25%
345 358 343 381 281 216 212
92
35%
483 501 481 492 475
485 460 323
50%
696 711 686 685
723 824 749 651
70%
984 991 968 964 1014 1084 1049 985
90%
1279 1268 1273 1290 1289 1288 1284 1265
Table 4-4. Pc=2000W table for pulse feedback (Unit:W)
10Hz 50Hz 150Hz 250Hz 500Hz 700Hz 1kHz 2kHz
10%
197 204 245 207 80 23 7 0
25%
497 498 507 568 537 538 501 335
35%
694 691 697 719 803 885 793 641
50%
990 982 976 984 1191 1264 1139 1049
70%
1380 1376 1368 1398 1508 1577 1503 1449
90%
1769 1758 1785 1801 1802 1812 1799 1776
