  2. FANUC Series 16i/160i-LB,LPB Pulse Power Feedback Function

FANUC Series 16i/160i-LB,LPB Pulse Power Feedback Function Additional Manual Page 3

Additional Manual
EDIT
DATE DESIGN
DESCRIPTION
TITLE
Pulse Power Feedback Function
A-81053-080
Page
２/16
01 04.09.14 M.Andou New registration
FANUC LTD
DR
A
W
No.
02 05.11.08 M.Andou Change of approx. power monitor
This function is applied from the following laser and software.
model Application
C1000-E,C2000-E,C4000-E
C5000-E,C6000-E
Since manufacturing
in October, 2004
model Series Versions
FS16i/16-i-LB B8H1 09
FS16i/160i-LPB B8H5 03
The time constant parameter of the power sensor (No.29006) was added from the
above-mentioned number of versions. It changed to the second approximate calculation of
the delay filter. As a result, the controllability of feedback has improved.
４．Correspondence to laser which has already been shipped
Please measure the time constant of the power sensor which is a peculiar parameter to
each laser (parameter No.29005) when you use this function with the oscillator which has
already been shipped, and set the parameter and the data table (Please refer to attached
material). We will describe the measuring method of the time constant later. Please set the
standard value as shown in the table below about the following parameters
(No.29000-29006) other than the time constant (No.29005).
And it is also possible to input the value of the table of attached material about the table
data by hand. However, please restore the data backed up from other CNC or request it to
FANUC because it is a common value in each model of the laser.
Standard set value of parameter
parameter
No.
Set value Remarks
29000 00000111 Set this parameter to 00000001 after setting
data.
29001 0 When No.29006 is not set, set this parameter
to 500 (Excluding C6000-E) and 1500
(Excluding C6000-E).
29002 0 When No.29006 is not set, set this parameter
to 500 (Excluding C6000-E) and 1500
(Excluding C6000-E).
29003 Rated power Unit:W
29004 10000 10 seconds
29005 880 (Excluding
C6000-E)
2240 (C6000-E)
Set this value by the measurement usually
automatically.
Unit:ms
29006 60 (Excluding
C6000-E)
300 (C6000-E)
Unit:ms
Attached material "DATA TABLE"
②
②
Previous page
Next page
