FANUC Series 16i/160i-LB,LPB Pulse Power Feedback Function Additional Manual Page 9

Additional Manual
EDIT
DATE DESIGN
DESCRIPTION
TITLE
Pulse Power Feedback Function
A-81053-080
Page
８/16
01 04.09.14 M.Andou New registration
FANUC LTD
DR
A
W
No.
02 05.11.08 M.Andou Change of approx. power monitor
Table 3-5. Pc=1500W table for pulse feedback (Unit:W)
10Hz 50Hz 150Hz 250Hz 500Hz 700Hz 1kHz 2kHz
10%
152 153 158 138 82 41 20 0
25%
378 379 386 404 375 335 321 259
35%
533 531 532 554 567 533 527 484
50%
763 759 757 760 855 815 804 787
70%
1067 1064 1062 1072 1157 1123 1117 1102
90%
1373 1367 1376 1384 1388 1377 1382 1376
Table 3-6. Pc=1750W table for pulse feedback (Unit:W)
10Hz 50Hz 150Hz 250Hz 500Hz 700Hz 1kHz 2kHz
10%
199 208 218 206 163 135 111 60
25%
499 502 526 546 552 539 544 536
35%
710 704 719 746 809 785 798 799
50%
1013 1005 1018 1029 1158 1140 1145 1158
70%
1421 1412 1423 1453 1550 1526 1537 1537
90%
1822 1822 1852 1864 1874 1858 1868 1868
Table 3-7. Pc=2000W table for pulse feedback (Unit:W)
10Hz 50Hz 150Hz 250Hz 500Hz 700Hz 1kHz 2kHz
10%
247 260 291 287 254 246 233 192
25%
622 623 667 712 775 770 776 808
35%
878 869 903 957 1093 1067 1084 1121
50%
1260 1240 1273 1303 1508 1488 1497 1533
70%
1764 1753 1783 1842 1968 1938 1956 1974
90%
2265 2271 2313 2329 2342 2331 2346 2355
Table 3-8. Pc=2700W table for pulse feedback (Unit:W)
10Hz 50Hz 150Hz 250Hz 500Hz 700Hz 1kHz 2kHz
10%
263 279 321 321 295 300 296 262
25%
665 666 725 781 871 869 874 928
35%
943 932 975 1042 1214 1188 1205 1248
50%
1355 1339 1377 1415 1654 1635 1645 1682
70%
1355 1339 1377 1415 1654 1635 1645 1682
90%
1355 1339 1377 1415 1654 1635 1645 1682
Table４ C4000-E standard data table and recommended area of pulse instruction
