  2. FANUC Series 16i/160i-LB,LPB Pulse Power Feedback Function

FANUC Series 16i/160i-LB,LPB Pulse Power Feedback Function Additional Manual Page 4

Additional Manual
EDIT
DATE DESIGN
DESCRIPTION
TITLE
Pulse Power Feedback Function
A-81053-080
Page
３/16
01 04.09.14 M.Andou New registration
FANUC LTD
DR
A
W
No.
02 05.11.08 M.Andou Change of approx. power monitor
Table１ C1000-E standard data table and recommended area of pulse instruction
（A gray area where stability is confirmed is recommended. ）
Value in table：Feedback target value of pulse instruction (Unit:W)
Table 1-1. Pc=125W table for pulse feedback (Unit:W)
10Hz 50Hz 150Hz 250Hz 500Hz 700Hz 1kHz 2kHz
10%
4 6 6 0 0 0 0 0
25%
28 31 32 34 25 16 2 0
35%
43 44 44 47 42 33 22 16
50%
59 60 61 62 62 58 48 61
70%
79 79 78 77 78 78 77 137
90%
93 92 91 91 100 112 134 203
Table 1-2. Pc=250W table for pulse feedback (Unit:W)
10Hz 50Hz 150Hz 250Hz 500Hz 700Hz 1kHz 2kHz
10%
28 28 27 19 0 0 0 0
25%
70 71 67 68 50 36 18 2
35%
94 95 90 90 77 62 45 34
50%
130 129 125 122 112 102 85 104
70%
175 173 167 163 153 150 152 208
90%
215 211 206 203 212 221 241 298
Table 1-3. Pc=375W table for pulse feedback (Unit:W)
10Hz 50Hz 150Hz 250Hz 500Hz 700Hz 1kHz 2kHz
10%
41 41 36 27 2 0 0 0
25%
105 104 96 98 74 55 31 8
35%
143 141 133 132 113 91 70 57
50%
198 195 186 182 165 154 133 153
70%
268 264 255 249 234 233 236 283
90%
334 328 321 319 327 334 350 396
Table 1-4. Pc=500W table for pulse feedback (Unit:W)
10Hz 50Hz 150Hz 250Hz 500Hz 700Hz 1kHz 2kHz
10%
56 53 49 38 10 0 0 0
25%
140 138 129 131 99 77 47 23
35%
190 188 178 175 152 124 99 83
50%
266 261 250 245 223 211 187 204
70%
361 355 344 336 317 322 322 360
90%
449 442 433 432 440 445 458 496
