FANUC Series 16i/160i-LB,LPB Pulse Power Feedback Function Additional Manual Page 5

Additional Manual
EDIT
DATE DESIGN
DESCRIPTION
TITLE
Pulse Power Feedback Function
A-81053-080
Page
４/16
01 04.09.14 M.Andou New registration
FANUC LTD
DR
A
W
No.
02 05.11.08 M.Andou Change of approx. power monitor
Table 1-5. Pc=625W table for pulse feedback (Unit:W)
10Hz 50Hz 150Hz 250Hz 500Hz 700Hz 1kHz 2kHz
10%
68 66 63 50 22 4 0 0
25%
173 169 162 164 129 104 68 36
35%
238 232 223 221 198 166 137 115
50%
331 325 313 309 275 264 250 263
70%
449 443 432 425 408 417 414 444
90%
563 556 546 545 554 557 569 598
Table 1-6. Pc=750W table for pulse feedback (Unit:W)
10Hz 50Hz 150Hz 250Hz 500Hz 700Hz 1kHz 2kHz
10%
83 80 77 64 32 12 0 0
25%
206 203 197 201 164 136 92 54
35%
284 279 270 271 249 214 181 152
50%
400 391 379 378 311 311 323 329
70%
544 535 526 520 486 523 514 533
90%
682 675 664 667 674 676 685 708
Table 1-7. Pc=875W table for pulse feedback (Unit:W)
10Hz 50Hz 150Hz 250Hz 500Hz 700Hz 1kHz 2kHz
10%
96 95 93 78 42 23 0 0
25%
241 237 235 241 200 173 123 74
35%
333 327 320 326 302 269 233 194
50%
468 459 448 449 435 436 403 404
70%
641 631 624 619 621 633 622 631
90%
804 797 790 793 800 801 808 823
Table 1-8. Pc=1000W table for pulse feedback (Unit:W)
10Hz 50Hz 150Hz 250Hz 500Hz 700Hz 1kHz 2kHz
10%
108 108 106 90 52 30 0 0
25%
271 268 270 274 235 209 152 95
35%
375 368 363 373 355 315 281 238
50%
526 517 508 510 512 503 475 472
70%
721 711 706 701 716 724 713 715
90%
906 898 895 899 906 904 909 919
Table２ C2000-E (B301,B311) standard data table
