FANUC Series 16i/160i-LB,LPB Pulse Power Feedback Function Additional Manual Page 12

Additional Manual
EDIT
DATE DESIGN
DESCRIPTION
TITLE
Pulse Power Feedback Function
A-81053-080
Page
１１/16
01 04.09.14 M.Andou New registration
FANUC LTD
DR
A
W
No.
02 05.11.08 M.Andou Change of approx. power monitor
（A gray area where stability is confirmed is recommended. ）
Value in table：Feedback target value of pulse instruction (Unit:W)
Table 5-1. Pc=560W table for pulse feedback (Unit:W)
10Hz 50Hz 150Hz 250Hz 500Hz 700Hz 1kHz 2kHz
10%
45 52 70 68 54 40 18 34
25%
111 122 152 189 192 174 156 238
35%
163 170 195 234 264 251 248 390
50%
227 235 261 294 354 348 368 635
70%
318 329 351 381 423 432 522 888
90%
408 421 440 445 522 584 694 1067
Table 5-2. Pc=1130W table for pulse feedback (Unit:W)
10Hz 50Hz 150Hz 250Hz 500Hz 700Hz 1kHz 2kHz
10%
117 115 127 122 93 69 31 31
25%
294 295 296 321 326 289 253 321
35%
411 409 412 424 456 410 405 541
50%
587 589 589 595 617 594 628 891
70%
824 818 829 831 820 833 937 1262
90%
1060 1063 1042 1069 1138 1195 1284 1566
Table 5-3. Pc=1690W table for pulse feedback (Unit:W)
10Hz 50Hz 150Hz 250Hz 500Hz 700Hz 1kHz 2kHz
10%
176 170 180 177 136 103 52 34
25%
443 435 430 448 462 408 361 408
35%
615 615 607 604 639 578 580 698
50%
888 883 874 865 864 843 915 1137
70%
1245 1245 1237 1226 1213 1241 1363 1616
90%
1598 1611 1595 1617 1682 1721 1795 2001
Table 5-4. Pc=2250W table for pulse feedback (Unit:W)
10Hz 50Hz 150Hz 250Hz 500Hz 700Hz 1kHz 2kHz
10%
230 224 238 237 191 148 76 48
25%
575 572 563 579 606 545 490 515
35%
811 803 795 792 831 763 782 867
50%
1161 1159 1146 1132 1122 1121 1222 1402
70%
1631 1635 1622 1608 1605 1647 1783 1971
90%
2116 2113 2096 2126 2193 2220 2282 2444
