FANUC Series16i/18i/21i
Cs-axis Coordinate Establishment
Function
A
-78845EN
Sheet
Signal Address
#7 #6 #5 #4 #3 #2 #1 #0
G274 CSFI4 CSFI3 CSFI2 CSFI1
#7 #6 #5 #4 #3 #2 #1 #0
F048 CSPENA
#7 #6 #5 #4 #3 #2 #1 #0
F052 CSPENB
#7 #6 #5 #4 #3 #2 #1 #0
F171 CSPENC
#7 #6 #5 #4 #3 #2 #1 #0
F269 CSPEND
#7 #6 #5 #4 #3 #2 #1 #0
F274 CSFO4 CSFO3 CSFO2 CSFO1
Alarm and message
Number Message Description
5346 RETURN TO REFERENCE POINT Cs coordinate establishment function
was aborted.
Perform manual reference point
return of Cs axis.
1. CSFIx was set to 1 even if CSPENx
was 0.
2. Position data was not transferred
from spindle amplifier.
3. Started synchronous /composite
/overlap control during
establishing Cs axis coordinate.
4. Released composite control during
establishing Cs axis coordinate.
5. Emergency stop during
establishing Cs axis coordinate.
6. Both direction pitch error
compensation was avlaiable for Cs
axis.
7. Cs axis was in servo off state.
Previous page
Next page
