FS 16i/18i/21i - TB / MB Additional Manual Page 8

Additional Manual
02 Sep.30.’03 Modification at (2)
Edit Date Design Description
Date Apr.14.2003 Desig. T.Watanabe Apprv. T.Endo
Sheet
Title
Draw
No.
8
/
14
FANUC Series16i/18i/21i
Cs-axis Coordinate Establishment
Function
A
-78845EN
Sheet
#7 #6 #5 #4 #3 #2 #1 #0
4353 CSPTRE
[Data type] Bit axis
CSPTRE The function that transfer position data of Cs axis is
0: Not used
1: Used
Set parameter RFCHK3(No.4016#7) to 0 in order to use this function.
#7 #6 #5 #4 #3 #2 #1 #0
8161 CZM
[Data type] Bit
CZM When two Cs contour axes are subject to composite control, the function for
composite zero point return commands for Cs contour axes is:
0: Not used
1: Used
Set CZM to 1 if you use Cs axis coordinate establishment function
during composite control. In case that CZM is 0, P/S alarm 5346
occurs.
Signals
Cs axis coordinate establishment request signals
CSFI1 ∼ CSFI4<G274#4∼#7>
[Classification] Input signal
[Function] Execute Cs axis coordinate establishment function
[Operation]
When CSFIx is 1 in Cs contour control mode, absolute coordinate and machine
coordinate are established according to Cs axis machine position.
When CSFIx are set to 0, Cs axis coordinate establishment alarm signal
CSFOx<F274#4-#7> are set to 0.
(2)
