FS 16i/18i/21i - TB / MB Additional Manual Page 7

Additional Manual
02 Sep.30.’03 Modification at (2)
Edit Date Design Description
Date Apr.14.2003 Desig. T.Watanabe Apprv. T.Endo
Sheet
Title
Draw
No.
7
/
14
FANUC Series16i/18i/21i
Cs-axis Coordinate Establishment
Function
A
-78845EN
Sheet
Parameter
#7 #6 #5 #4 #3 #2 #1 #0
1005 ZRN
[Data type] Bit axis
ZRNx When a command specifying the movement except for G28 is issued in
automatic operation (MEM, RMT, or MDI) and when a return to the reference
position has not been performed since the power was turned on
0: An alarm is generated (P/S alarm 224).
1: An alarm is not generated.
We recommend you to set ZRNx to 0 for Cs axis coordinate establishment
function.
#7 #6 #5 #4 #3 #2 #1 #0
3700 NRF
[Data type] Bit
NRF The first move comm and (such as G00 and G01) after the serial spindle is
switched to Cs axis contouring control performs:
0: Positioning after returning to the reference position.
1: Normal positioning.
We recommend you to set NRF to 1 for Cs axis coordinate establishment
function.
#7 #6 #5 #4 #3 #2 #1 #0
3712 CSF
[Data type] Bit
CSF Cs axis coordinate establishment function is
0: Not used
1: Used
