FS 16i/18i/21i - TB / MB Additional Manual Page 2

Additional Manual
02 Sep.30.’03 Modification at (2)
Edit Date Design Description
Date Apr.14.2003 Desig. T.Watanabe Apprv. T.Endo
Sheet
Title
Draw
No.
2
/
14
FANUC Series16i/18i/21i
Cs-axis Coordinate Establishment
Function
A
-78845EN
Sheet
General
Generally, position is lost just after changing serial spindle mode from speed
control mode to Cs contour control mode.
This function makes it possible to establish position without reference point
return by setting Cs axis coordinate establishment request signal
CSFIx<G274#4∼#7> to 1.
Setting
Set the parameter CSF(No.3712#2) and the parameter CSPTRE (No.4353#5) to
1 in order to use Cs axis coordinate establishment function.
(The parameter RFCHK3(No.4016#7) is set to 0 in order to use this function.)
And, the M code that sets Cs axis coordinate establishment request signal
CSFIx<G274#4∼#7> to 1 must be preventing buffering. Set the value of the M
code to parameter No.3411 to 3432.
If you use Cs axis coordinate establishment function under composite control,
set the parameter CZM(No.8161#1) to 1.
Method of Cs axis coordinate establishment
(1) According to M code, change serial spindle mode to Cs contour control mode
and set Cs axis coordinate establishment request signal
CSFIx<G274#4∼#7> to 1 at the same time.
(2) If Cs axis zero point establishment state signal CSPENx is 1, absolute
coordinate, relative coordinate, and machine coordinate of Cs axis are
counted up in order to establish them.
(3) After coordinate has been established, reference point establishment signal
ZRFx<F0120#0∼#7> is set to 1. Then, set Cs axis coordinate establishment
request signal CSFIx<G274#4∼#7> to 0.
(4) Execute FIN sequence for M code.
Note
This function is available from finish of the first reference point return of Cs
contour axis until power-off.
