FANUC Series16i/18i/21i
Cs-axis Coordinate Establishment
Function
A
-78845EN
Sheet
Apply software, hardware
The following software are needed in order to use Cs axis coordinate
establishment function.
NC system software
Series-Edition
FS16i/160i/160is-TB B1HA-06 or later
FS18i/180i/180is-TB BEHA-06 or later
FS21i/210i/210is-TB DEHA-06 or later
FS16i/160i/160is-MB B0HA-04 or later
FS18i/180i/180is-MB BDHA-04 or later
FS21i/210i/210is-MB DDHA-04 or later
FS18i/180i/180is-MB5 BDH5-19 or later
αi spindle software
Series-Edition
9D50-07 or later
Hardware
When Cs axis coordinte establishment funcion does not work even if you use
applied software, please confirm diagnose No.400#7 in diagnostic screen.
If diagnose No.400#7 is 0, hardware may not be applied to Cs axis coordinate
establish function. Please contact with FANUC.
#7 #6 #5 #4 #3 #2 #1 #0
400
