Manual for Synchronous Spindle Motor Drive Additional Manual Page 8

Additional Manual
8
Manual for
Synchronous Spindle Motor Drive
EDT. DATE DESIG. DESCRIPTION PAGE /29
A-63639E-103 /03
NO.
TITLE
NEWLY Y.Toyozawa
K.Takahashi
2003.06.13 01
02 2003.10.15 K.Takahashi
A
dded SSM etc. Y.Toyozawa
03 2004.06.09 K.Takahashi Revised Pole detect, etc. Y.Toyozawa
15i 16i 30i 5
th
4
th
3
rd
2
nd
1
st
(9D53/C, 9D70/B or later)
3450 4450 4450 5
th
, 4
th
, 3
rd
digit: Magnification to movable detection angle (unit: %)
2
nd
, 1
st
digit: Magnification to velocity feedback threshold (unit: %)
When Minute moving mode is executed at Auto mode of pole detection, this parameter is used.
This parameter must be set “0” if the software except the above is used. Please refer to chapter 7 (Pole
position detection function) about this parameter.
15i 16i 30i 5
th
4
th
3
rd
2
nd
1
st
(9D53/C, 9D70/B or later)
3451 4451 4451 5
th
digit: Selection of excitation phase
4
th
, 3
rd
digit: Time constant for excitation current decays (unit: 0.1sec)
2
nd
, 1
st
digit: Final value for excitation current decays (unit: %)
This parameter is used for variable excitation current at DC current mode of pole detection.
This parameter must be set “0” if the software except the above is used. Please refer to chapter 7 (Pole
position detection function) about this parameter.
