E.2 SPECIFICATIONS
E.2.1 PANEL i (For Series 150i/160i/180i/210i/Power Mate i-D/H)
Item PANEL i with Pentium M PANEL i with Pentium III
PC Unit (Basic Unit)
CPU
Pentium M 1.6GHz or
Celeron M 1.3GHz
Pentium III 1.26GHz,
Pentium III 866MHz or
Celeron 733MHz
Memory 1GB, 512M or 256MB 512MB, 256M or 128MB
LCD
15.0”XGA (1024x768dot),
12.1”SVGA (800x600dot),
10.4”SVGA (800x600) or
10.4”VGA (640x480)
Note) Windows XP cannot be used on 10.4”
VGA type unit.
As same as left
Touch-Panel 1024x1024 dots (Option)
As same as left
Display
Unit
Soft key
Horizontal 12 keys (Option)
Note) Available only in case of connecting to
CNC via HSSB.
As same as left
Serial Port
2 ports (Port 1 cannot be used with touch panel
option)
As same as left
USB
Based on USB 2.0
2 ports (rear, USB connector)
2 ports (for Punch panel, Note 1)
Based on USB 1.1
2 ports (rear, USB connector,
or for Punch panel)
Parallel port
1 port (Data transfer mode is by-directional
mode)
As same as left
Full Keyboard 1 port (PS/2 compatible) As same as left
Mouse 1 port (PS/2 compatible) As same as left
IDE
2 ports/4 devices (Signal connector: IBM PC
compatible)
As same as left
Floppy disk 1 port (Signal connector: IBM PC compatible) As same as left
Ethernet 1 port (10BASE-T/100BASE-TX) As same as left
Video port 1 port (analog RGB output) As same as left
HSSB (High Speed
Serial Bus)
1 port (An optical connector for the connection
with CNC controller)
As same as left
I/O port
PCMCIA Card slot 1 port (Type I/ II, based on PCMCIA 2.1) As same as left
PCI Extension 2 slots of the short card
Based on PCI specification 2.1,
32-bit, 33MHz, +5V
Maximum dimension of card: 176.41mm x
106.68mm
As same as left
Real time clock
Monthly error is within 3 minutes.
As same as left
